Hardware and model

Local LLM stackNote

It is a hybrid model, so the context is cheap.

Only about 16 of the 65 layers keep a KV cache that grows with context. That is the only reason 262144 tokens fit in 28 GB beside the weights. The other layers carry a fixed-size state, so dropping from q8_0 to q4_0 KV saves only about 4 GiB at full context.

The box

Part	Detail
GPU0	RTX 5070 Ti, 16 GB (16303 MiB usable), top slot, PCIe 5.0 x16
GPU1	RTX 4070, 12 GB, bottom slot, PCIe 3.0 running at x4
Board	ASUS ROG STRIX B660-F GAMING WIFI
CPU	i7-13700K, 8 P-cores + 8 E-cores, 24 threads
RAM	32 GB
PSU	800 W

The x4 slot is fine for inference

Loading: 19 GB weights, about 90 s. Generating: 64–66 t/s measured. Same PCIe 3.0 x4 link, about 4 GB/s.

The 4070 sits in a chipset slot at PCIe 3.0 x4, about 4 GB/s. That makes loading slow: about 90 seconds to move 19 GB. It does not slow generation, because only small activations cross between the cards per token.

A prediction that was wrong

Before the second card went in, a chat assistant predicted the x4 slot would act "like a speed brake" and keep decode at 19 to 22 t/s. The measured result was 64 to 66 t/s. Measure, do not predict.

Power

Unverified

An 800 W supply is close to the limit with both cards under load. An unverified estimate from the same chat: 5070 Ti 250 to 300 W, 4070 200 to 220 W, CPU and the rest 150 to 200 W, spikes of 650 to 720 W. The suggested fix is a power limit of about 80 % on both cards, which it claimed costs 1 to 2 % of speed. I have not measured that.

# Example: cap GPU power (watts) with nvidia-smi. Pick values for your cards.
sudo nvidia-smi -i 0 -pl 240
sudo nvidia-smi -i 1 -pl 160

Resizable BAR is not the problem

Out-of-memory crashes with gigabytes free look like a BAR or MMIO problem. They were not. Both cards showed full 16 GB resizable BARs above 4 GB, and Above 4G Decoding was working. The real cause was context size. See Context and fit-target.

The model: Qwen3.8-27B is a hybrid

The GGUF metadata says general.architecture = qwen35. It is not a plain dense transformer.

Qwen3.8-27B · 65 blockscontext: 262144 · q8_0 KV ≈ 8.5 GiB at full context

• full attention (≈16 layers): KV cache grows with context
• Gated DeltaNet linear attention (≈48): fixed-size state
• separate MTP head: blk.64.nextn.*

Only ~16 of 65 layers pay for context. That is why 262144 fits in 28 GB.

qwen35.block_count             = 65
qwen35.full_attention_interval = 4      only every 4th layer is full attention
qwen35.ssm.state_size          = 128    the others are linear attention (Gated DeltaNet)
qwen35.attention.head_count_kv = 4
qwen35.attention.key_length    = 256
qwen35.context_length          = 262144

About 16 layers keep a KV cache that grows with context. About 48 carry a fixed-size recurrent state. -ctk and -ctv only change the KV cache, not the recurrent state.

The MTP draft head is inside the GGUF (blk.64.nextn.*, qwen35.nextn_predict_layers 1). You do not need a separate draft model.

KV cache cost

H3 / KV cache cost

Full context: 8.5 GiB.
q4_0 saves ~4 GiB, not 12.

4 KV heads × 256 dim × 2 (K+V) × bytes × ~16 layers

at 131072 tokens

q8_0 · 4.25 GiB

q5_1 · 3.0 GiB

no CUDA FA kernel

q4_0 · 2.25 GiB

at 262144 tokens

q8_0 · 8.5 GiB

q5_1 · 6.0 GiB

no CUDA FA kernel

q4_0 · 4.5 GiB

Dense-model comparison: ≈ 4x q8_0 at 262144

All bars share a 0–36 GiB scale. The dotted bar is an estimate, not a measurement.

On Unsloth Studio this estimate ran ~40 % low. Trust the server's fit log near the edge.

Formula: 4 KV heads x 256 head dim x 2 (K and V) x bytes per value x ~16 layers.

KV type	Per token	At 131072	At 262144
q8_0	34 KiB	4.25 GiB	8.5 GiB
q5_1	24 KiB	3.0 GiB	6.0 GiB
q4_0	18 KiB	2.25 GiB	4.5 GiB

A dense 65-layer model would need about four times this. Going from q8_0 to q4_0 saves about 4 GiB at full context, not the 12 GiB you might expect.

The estimate runs low

On Unsloth Studio this formula was about 40 % below what the server actually budgeted. Near the edge, trust the server's own fit log.

Valid KV types in llama.cpp

f32, f16, bf16, q8_0, q4_0, q4_1, iq4_nl, q5_0, q5_1. There is no FP8 KV cache in llama.cpp. Unsloth's FP8 advice is for their vLLM path.

On CUDA, flash attention only has kernels for f16, bf16, q8_0 and q4_0. The q5 types fall back to the CPU. That is why rule 4 exists.

Which quant

Published KL divergence against BF16 (lower is closer to the full model):

Quant	KL divergence	Top-1 agreement	Size
UD-Q4_K_XL	0.00955	96.02 %	17.9 GB
UD-Q5_K_XL	0.00437	97.28 %	about 20 GB
UD-Q6_K	0.00242	97.93 %	22.4 GB
Q8_0	0.00064	98.93 %	28.9 GB

What I use and why:

• UD-Q4_K_XL is the daily driver on both servers. It leaves the most room for context and MTP.
• UD-Q6_K runs on Unsloth Studio at 98304 context. It costs 8 to 10 % of speed against Q4.
• UD-Q5_K_XL was used on llama-swap for three days. It was replaced when Q4 plus full context turned out faster.
• Only one vision projector is kept, mmproj-Qwen3.8-27B-F16.gguf, renamed from the generic mmproj-F16.gguf so two models could not collide.

Unverified claims about the quants

Unverified

These came from a NotebookLM summary of YouTube videos. They are not checked.

• UD-Q4_K_XL uses Unsloth Dynamic quantization with an importance matrix and keeps sensitive tensors at 5 bits or more.
• Unsloth replaced its GGUF builds on 19 August. Pin a Hugging Face revision if you need reproducible results.
• Plain uniform Q4 weights may damage the gated delta layers and cause silent drift.

Community reading

• How can I run this well on an RTX 5070 Ti?, a Hugging Face discussion on the model page.
• Qwen3.8-27B Local Hardware Guide on kingy.ai.
• Unsloth's Qwen3.8 docs for quants and sampling.

Next step: llama-swap setup
