Pitfalls and fixes

Local LLM stackRunbook

Find the symptom, apply the fix, check the CPU layers.

Start with the symptom table. If your problem is not there, the "What did not work" list shows what has already been ruled out. When speed drops, count the layers on the CPU before you change anything else.

Symptom table

Symptom	Likely cause	Fix
Decode under 20 t/s, VRAM looks full	Layers spilled to the CPU	Count CPU layers. Lower -c or set -fitt 128
About 75 t/s prefill, GPU use 0 %, CPU at 1500 %	KV type is q5_1 or q5_0	Use q8_0 or q4_0
Loads, passes /health, crashes on first reply	Context too big for compute buffers	Lower -c, re-tune -fitt, test with a long prompt
Q5 model will not load at any tensor split	-ngl and --tensor-split pinned	Remove both. Let auto-fit place layers
"MTP could not start" on Unsloth Studio	GPU Memory set to Manual	Set Auto, add --fit-target 128
failed to create MTP context on any context	The quant stripped the MTP tensors	Use a quant that keeps MTP
Replies come back empty	Text is in reasoning_content, or stock template at xhigh	Read reasoning_content. Set effort to medium
"Ran out of output-token budget twice"	Thinking used all of max_tokens	Set --reasoning-budget well below max_tokens
Server 500 on a request with reasoning_effort: none	The stock template raises on none	Use --reasoning-budget 0 or enable_thinking: false
Fast 404 from llama-swap	Wrong or wrong-case model name	Use the id or an alias
500 or 502 "upstream exited prematurely"	llama-server crashed	Run the command by hand to see the real error
Client 502 with no server error	Host out of memory, oom-kill	Check journalctl. 262144 on Studio used about 25 GiB of RAM
Speed halves when ComfyUI runs	GPU1 has no margin left	curl :8081/unload first, or raise -fitt to 256
dsh reports context overflow, or truncates	Its settings drifted from the server	uctl sync, then restart the desktop app
invalid argument: -fitt 128	zsh passed two words as one argument	Use an array or bash

What did not work

Tried	Result	Why
-ngl 48 on one GPU	Loaded at 15659 MiB, crashed on first decode	Compute buffers allocate on first use. 42 was the real ceiling
--tensor-split 18,10 or 17,11	Failed	The split must match the cards, and should not be set at all
Pinned -ngl 99 and split with UD-Q5_K_XL	Would not load at any of six ratios	Pinning disables auto-fit
Default --fit-target (1024) at 262144	10 CPU layers, 25.8 t/s	Margin too large for this box
-sm row	41.2 t/s against 52.3	PCIe traffic costs more than one CPU layer
-sm tensor	Out of memory on load	Experimental upstream
No MTP	28.8 t/s against 51+	MTP is worth +78 % on llama-swap
GGML_CUDA_DISABLE_GRAPHS=1	Breaks the dual-GPU setup	It was a single-GPU workaround
q5_1 or q5_0 KV on Unsloth Studio	13.8 t/s decode, GPU idle	No CUDA flash-attention kernel
Q6_K at 131072 with q8_0 KV	27.3 t/s, silent spill	Weights, KV and MTP reserve exceed free VRAM
262144 context on Unsloth Studio	About 25 % slower, fragile	The fork's fit is marginal at full context
--reasoning-preserve in agent loops	Every step replays every earlier thought	Fine for chat only
--reasoning-budget equal to max_tokens	No tokens left for the answer	Thinking counts against max_tokens
reasoning_effort: low	Same quality, more thinking than medium	The first test used one prompt
reasoning_effort: xhigh	8.1 times the thinking of medium	Runs out of budget mid-thought
Bare "do not second-guess" rules	5 times more thinking	Naming the loop feeds it
Three models for three agent roles	15 s reload, 30 to 60 times per task	Only one model fits at a time
--spec-draft-p-min 0.75 (on a 9B MTP model)	116.5 t/s against 144.2 at 0	The gate throws away free tokens

How the config got here

When	Config	Decode
Start, one GPU	Q4_K_M, -ngl 42, 65536	22.7 t/s
One GPU, FFN of 34 layers on the CPU	65536	23.8 t/s
Second GPU added, -ot offload line deleted	-ngl 99 --tensor-split 16,12, q8_0, 98304	64 to 66 t/s
16 Aug	UD-Q5_K_XL, auto-fit, 98304, q8_0	53.9 to 56.9 t/s
16 Aug	Effort medium, budget 2048, preserve removed	Thinking fixed on llama-swap
18 Aug	163840 with q5_1 KV	52.3 t/s
19 Aug	UD-Q4_K_XL, 262144, q4_0, -fitt 128	52.3 t/s
27 Aug	Studio: GPU Memory Auto, --fit-target 128	17 to 52.5 t/s
28 Aug	Studio: Q6_K knee found at 98304	48.6 t/s
31 Aug	Studio q4-agent, budget 12288, effort medium	53.8 t/s

The biggest single win was deleting one line: the -ot rule that kept feed-forward weights on the CPU. On one 16 GB card it was needed. With 28 GB it only cost speed.

Removed: -ot, -ngl, --tensor-split, -sm, GGML_CUDA_DISABLE_GRAPHS, --reasoning-preserve.
Kept: -fitt 128.

When in doubt, remove a flag

Almost every speedup in this table came from removing a setting or using a default: the offload line, -ngl, --tensor-split, -sm, GGML_CUDA_DISABLE_GRAPHS, --reasoning-preserve. The one flag that had to be added was -fitt 128.
